Kino-flo Foto-Flo 400 Manual do Utilizador

Operation Manual Foto-Flo 400 Part No. 3100007 Rev B

10 KAS-C46 6-Lamp Carry Case, (4ft) MTP-K41 “Twist-On” Mount w/ 3/8” Pin MTP-B41S “Twist-On” Mount w/

11 X16-A4 4Bank to Single Splitter X16-A9 4Bank to Double Splitter FIX-F4 Foto-Flo 400 Fixture Shell

12 See web site: www.kinoflo.com for more repair parts KAS-C46

13 BAL-422-120Foto-Flo 400 Ballast, 120VAC Input Voltage: 120VAC 50/60Hz Outp

14 Environmental: Disposal of Old Electrical & Electronic Equipment.

2 .. KIT-F4-120 Foto-Flo 400 Kit, 120vac

3 Each System consists of: 1 Foto-Flo 400 Fixture 1 Mo

4 The Foto-Flo 400 fixture is comprised of a removable Louver, Reflector, and Lamp Harness. The Louver and

5 Locking Lamp Connector: Depress both tabs on lamp connector and apply to lamp pins. Match the Harness c

6 Align the center pin of the mounting plate to the center hole on the mating plate. Rotate plate clo

7 Optional Lollipops allow mounting to grip heads or baby stands. To remove the plate, pull up on the lockin

8 1. Connect the harness to the Ballast. Align the key ways on the harness connector with the circular rece

9 WARNING! 1) ALWAYS TURN OFF THE BALLAST BEFORE connecting or disconnecting Lamps, Harnesses or Extensio
